關于我們

庫特勒自動化系統(蘇州)有限公司成立于 1988 年，專注于印刷

電路板行業和光伏產業設備、整體自動化解決方案的研發、生

產和服務，為全球超過 100 家客戶提供高效快捷的產品和服務。

公司自主研發制造的自動化設備及其整體自動化解決方案，廣

泛應用于德國、美國、日本、意大利、印度、俄羅斯等國家和

地區，獲得市場廣泛...

軟板蝕刻-剝膜線

Specifications/規格：
Panel size max: 610x610mm
Panel thickness (incl. Cu): 50µm-4.0mm
Line width/space: 2mil/2mil (1mil/1mil)
Aspect ratio through hole: 15:1
Aspect ratio blind hole: 2:1
Etching capability
uniformity 93%
etching factor >4
Flexible for alkaline-base or organic-base stripper system
Unbalance copper thickness board 1:2 1:3

Specified by Customer/可定制規格：
Working height, width & direction
Line speed
Conveyor type, etc.

剝膜蝕刻-剝錫線

Specifications/規格：
Panel size max: 620x620mm
Panel thickness (incl. Cu): 0.3mm-7.0mm
Line width/space: 2mil/2mil
Aspect ratio through hole: 15:1
Aspect ratio blind hole: 2:1
Etching capability
uniformity 93%
etching factor >4
Flexible for alkaline-base or organic-base stripper system
Unbalance copper thickness board 1:2 1:3

Specified by Customer/可定制規格：
Working height, width & direction
Line speed
Conveyor type, etc.

V 200

Specifications/規格：
Panel thickness: 0.03mm-3.20mm
Panel size max: 610x610mm
Panel size min: 300x300mm
L-Rank stacking height max: 200mm
Cycle time: 10sec/panel
Panel weight max: 2kg/panel
Warping & twisting of panels max: 1% on panel edge
Working height: 920±50mm
Power supply: 220V/50Hz/0.28Kw/1.30A
Air consumption: 75L/min

軟板顯影線

Specifications/規格：
Panel size max: 250x500mm
Panel thickness (incl. Cu): 0μm-1.6mm
Aspect ratio through hole: 4:1
Aspect ratio blind hole: 2:1
Conveyor speed: 0.2-6m/min
Working height: 950mm±50mm

Specified by Customer/可定制規格：
Working height, width & direction
Line speed
Conveyor type
Processed materials,etc.

減薄銅線

Specifications/規格：
Panel size max: 508x610mm
Panel thickness (incl. Cu): 0.3-3.2mm
Uniformity: 94%
Conveyor speed: 0.2-6m/min
Working height: 950mm±50mm

Specified by Customer/可定制規格：
Working height, width & direction
Line speed
Conveyor type
Processed materials, etc.
